 深圳市盈源电子有限公司
Shenzhen YingYuan Electronics Co., Ltd Address:The 4-7th Floor, Building 8, HongYe Industrial Park, XiXiang Town, BaoAn District, ShenZhen, China |
FEATURES | SAFETIES APPROVALS | PRODUCTS PICTURE |
v EFFICIENCY VI v 0-6 WATT OUTPUT POWER v OVERCURRENT PROTECTION v SHORT CIRCUIT PROTECTION v INPUT PROTECTION v ROHS COMPLIANT |
v KC v KCC v ROHS v REACH
|  |
TYPICAL MODEL LIST |
I/P Voltage | Typical model | Output Voltage | Output Current | Ripple & noise | Efficiency |
90 - 264V 47 - 63HZ | SAW06-050-0500 | 5V | 500mA | 30mV | VI |
SAW06-050-1000 | 5V | 1000mA | 40mV | VI |
SAW06-050-1200 | 5V | 1200mA | 50mV | VI |
SAW06-090-0500 | 9V | 670mA | 70mV | VI |
SAW06-120-0500 | 12V | 500mA | 50mV | VI |
SAW06-240-0250 | 24V | 250mA | 50mV | VI |
INPUT SPECIFICATIONS | GENERAL SPECIFICATIONS |
Input Voltage | 90〜264VAC | Primary to Secondary | 50MΩ MIN |
Input Frequency | 47〜63Hz | Efficiency | VI |
Input Current | 1.2A Max | Standby Power | 0.1W MAX |
Inrush Current | 40A Max | Leakage Current | 0.25mA MAX |
OUTPUT SPECIFICATIONS | ENVIRONMENTAL SPECIFICATIONS |
Output Voltage Range | 5V-24V | Operating Temperature | 10°C~40°C |
Output Current Range | 100mA-1200mA | Cooling | Convection |
Output Power Range | 6W Max | Temperature Coefficient | 0.05%/°C |
Short Circuit Protection | Automatic Recovery | Humidity | 5~95%RH(non-condensing) |
Over-Current Protection | Automatic Recovery | Storage Temperature | -20°C~+80%°C |
Ripple and Noise | 100mVp-p max | PHYSICAL SPECIFICATIONS |
Turn On Time | 20-30mS normal | Physical Specifications | 42mm * 38.7mm * 23.7mm |
Line Regulation | 1% max | SAFETIES STANDARD |
Output Regulation | ±5% | Safeties Standard | 60950/ 60335/ 61558/ 60065 |
MECHANICAL SPECIFICATION | PACKING DETAILS |
| 300pcs/carton,15kg/carton Carton size: 47*36.5*19cm
|
Why Choose US?
Profession: 12 Years' R&D Innovation Capability, AC DC Power Adapter Manufacturer in Shenzhen China(Offer OEM & ODM Service).
Strong: 900 Employees Chinese Factory,30 Professional R&D Engineer,60 QC Members,Monthly Deliverability 2100000pcs
Service: Competitive Price,Free Sample, 25 Working Days Lead Time.
Reliable: Energy Efficiency Level VI with 3 years Warranty,and CE,CB,GS,BSMI,UL,FCC,CA prop 65,SAA,RCM,NOM,PSE,KC,KCC,CCC,RoHS,REACH Certified and Class II Construction.
Comprehensive: Wall-mounted Adapter,USB Charger,Interchangeable plugs,Desktop Power Supplies,Type C charger, Quick Charger,Car Charger and Wireless Charger.
